Product Summary
The ISP1581BD is a Universal Serial Bus (USB) interface device. It provides high-speed USB communication capacity to systems based on a microcontroller or microprocessor.
Parametrics
Absolute maximum ratings: (1)supply voltage:-0.5V to +6.0V; (2)input voltage:-0.5V to VCC+0.5V; (3)latchup current:200mA; (4)storage temperature:-60℃ to +150℃.
Features
Features: (1)Complies fully with Universal Serial Bus Specification Rev. 2.0; (2)Complies with most Device Class specifications; (3)Supports automatic USB 2.0 mode detection and USB 1.1 fall-back mode; (4)High speed DMA interface; (5)Fully autonomous and multi-configuration DMA operation; (6)Up to 14 programmable USB endpoints with 2 fixed control IN/OUT endpoints; (7)Integrated physical 8 kbyte of multi-configuration FIFO memory; (8)Operating temperature range -40℃ to +85℃; (9)12 kV in-circuit ESD protection on human accessible pins such as D+ and D-; (10)Full-scan design with high fault coverage (>99%); (11)Available in LQFP64 package.
Diagrams
Image | Part No | Mfg | Description | Pricing (USD) |
Quantity | |||||
---|---|---|---|---|---|---|---|---|---|---|
ISP1581BD |
IC USB PERIPHERAL CTRLR 64-LQFP |
Data Sheet |
Negotiable |
|
||||||
ISP1581BD-S |
IC USB CTRL HI-SPEED 64LQFP |
Data Sheet |
Negotiable |
|
||||||
ISP1581BD-T |
IC USB CTRL HI-SPEED 64LQFP |
Data Sheet |
Negotiable |
|
