Product Summary
The HCPL-7840 is an Analog Isolation Amplifier. It provides accurate, electrically isolated and amplified representations of voltage and current. When used with a shunt resistor in the current path, the HCPL-7840 offers superior reliability, cost effectiveness, size and autoinsertability compared with the traditional solutions such as current transformers and Halleffect sensors. The HCPL-7840 consists of a sigma-delta analog-to-digital converter optically coupled to a digital-to-analog converter. The applications of the HCPL-7840 are Motor Phase and Rail Current Sensing, Inverter Current Sensing, Switched Mode Power Supply Signal Isolation, General Purpose Current Sensing and Monitoring, General Purpose Analog Signal Isolation.
Parametrics
HCPL-7840 absolute maximum ratings: (1)Storage Temperature:-55℃ to 125℃; (2)Ambient Operating Temperature:-40℃ to 85℃; (3)Supply Voltages:0.0V to 5.5V; (4)Steady-State Input Voltage:-2.0V to VDD1+0.5V ; (5)2 Second Transient Input Voltage:-6.0V to VDD1+0.5V; (6)Output Voltages:-0.5V to VDD2+0.5V; (7)Lead Solder Temperature(10 sec., 1.6 mm below seating plane):260 ℃.
Features
HCPL-7840 features: (1)High Common Mode Rejection (CMR): 15 kV/μs at VCM = 1000 V; (2)5% Gain Tolerance; (3)0.1% Nonlinearity; (4)Low Offset Voltage and Offset Temperature Coefficient; (5)100 kHz Bandwidth; (6)Performance Specified Over -40℃ to 85℃ Temperature Range; (7)Recognized Under UL 1577 and CSA Approved for Dielectric Withstand Proof Test Voltage of 2500 Vac, 1Minute; (8)Standard 8-Pin DIP Package.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 HCPL-7840 |
Avago Technologies |
Isolation Amplifiers 4.5 - 5.5 SV 8 dB |
Data Sheet |
|
|
||||||||||||
|
HCPL-7840#060 |
Avago Technologies |
Isolation Amplifiers 4.5 - 5.5 SV 8 dB |
Data Sheet |
|
|
||||||||||||
|
HCPL-7840#300 |
Avago Technologies |
Isolation Amplifiers 4.5 - 5.5 SV 8 dB |
Data Sheet |
|
|
||||||||||||
|
HCPL-7840#560 |
Avago Technologies |
Isolation Amplifiers 4.5 - 5.5 SV 8 dB |
Data Sheet |
|
|
||||||||||||
|
HCPL-7840#500 |
Avago Technologies |
Isolation Amplifiers 4.5 - 5.5 SV 8 dB |
Data Sheet |
|
|
||||||||||||
|
HCPL-7840#360 |
Avago Technologies |
Isolation Amplifiers 4.5 - 5.5 SV 8 dB |
Data Sheet |
|
|
||||||||||||
|
HCPL-7840-300E |
Avago Technologies |
Isolation Amplifiers 4.5 - 5.5 SV 8 dB |
Data Sheet |
|
|
||||||||||||
|
HCPL-7840-500E |
Avago Technologies |
Isolation Amplifiers 4.5 - 5.5 SV 8 dB |
Data Sheet |
|
|
||||||||||||
