AD7836AS

four 14-bit DACs, LC2MOS Quad, 44-MQFP

Rated 5 Rating 5 | reviews | Write a review

Price:: US $1.00~1.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $1.00~1.00

PartNumber:: AD7836AS

Brand:: Analog Devices - ADI | Pack: DIP | D/C: 09+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. CoCo's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-05-03

From Other Seller

Part Number:AD7836AS
US $1.00 - 1.00
A50L-0001-0175

US $100.00 - 100.00 / Piece
(0) Remove
iphone5 data cable

US $4.00 - 5.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The AD7836AS contains four 14-bit DACs on one monolithic chip. It has output voltages with a full-scale range of ±10V from reference voltages of ±5V. The AD7836AS accepts 14-bit parallel loaded data from the external bus into one of the input latches under the control of the WR, CS and DAC channel address pins, A0–A2. The DAC outputs are updated individually, on reception of new data. In addition, the SEL input can be used to apply the user programmed value in DAC Register E to all DACs, thus setting all DAC output voltages to the same level. The contents of the DAC data registers are not affected by the SEL input. Each DAC output is buffered with a gain of two amplifier into which an external DAC offset voltage can be inserted via the DUTGNDx pins. The AD7836AS is available in a 44-lead MQFP package.

Contact: nancy2008chan@gmail.com

_{^{For more information or to order consultation, please EMAL us directly.}}

Parametrics

Absolute Maximum Ratings: (1)VCC to DGND: -0.3V, +7V or VDD + 0.3V (Whichever Is Lower); (2)VDD to AGND: -0.3V, +17V; (3)VSS to AGND: +0.3V, -17V; (4)AGND to DGND: -0.3V, +0.3V; (5)Digital Inputs to DGND: -0.3V, VCC+0.3V; (6)VREF(+) to VREF(-): -0.3V, +18V; (7)VREF(+) to AGND: VSS-0.3V, VDD+0.3V; (8)VREF(-) to AGND: VSS-0.3V, VDD+0.3V; (9)DUTGND to AGND: VSS-0.3V, VDD+0.3V; (10)VOUT (A-D) to AGND: VSS-0.3V, VDD+0.3V; (11)Operating Temperature Range Industrial (A Version): -40℃ to +85℃; (12)Storage Temperature Range: -65℃ to +150℃; (13)Junction Temperature: +150℃; (14)MQFP Package, Power Dissipation: 480mW; (15)θJA Thermal Impedance: 95℃/W; (16)Lead Temperature, Soldering of Vapor Phase (60 sec): +215℃; (17)Lead Temperature, Soldering of Infrared (15 sec): +220℃.

Features

Features: (1)Four 14-Bit DACs in One Package; (2)Voltage Outputs; (3)Separate Offset Adjust for Each Output; (4)Reference Range of ±5V; (5)Maximum Output Voltage Range of ±10V; (6)Clear Function to User-Defined Code; (7)44-Pin MQFP Package.
