HCPL-2232

Very High CMR, Wide VCC, Logic Gate Optocoupler, Low Input Current, 1.6 mA to 1.8 mA, Hysteresis

Rated 5 Rating 5 | reviews | Write a review

Price:: US $4.00~4.50 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $4.00~4.50

PartNumber:: HCPL-2232

Brand:: Agilent Technologies - Agilent | Pack: SOP | D/C: 01+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. CoCo's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-07-20

From Other Seller

Part Number:HCPL-2232
US $4.00 - 4.50
HT46R47

US $0.35 - 1.50 / Piece
(0) Remove
SIL9030CTU

US $2.50 - 5.10 / Piece
(0) Remove
Quantity:

piece

Product Summary

The HCPL-2232 is an optically-coupled logic gate. It contains a GaAsP LED. The detectors have totem pole output stages and optical receiver input stages with built-in Schmitt triggers to provide logic-compatible waveforms, eliminating the need for additional waveshaping. The applications of the HCPL-2232 are Isolation of High Speed Logic Systems, Computer-Peripheral Interfaces, Microprocessor System Interfaces, Ground Loop Elimination, Pulse Transformer Replacement, High Speed Line Receiver, Power Control Systems.

Parametrics

HCPL-2232 absolute maximum ratings: (1)Storage Temperature:-55℃ to +125℃; (2)Operating Temperature:-40℃ to +85℃; (3)Average Forward Input Current:10mA; (4)Peak Transient Input Current:1.0A; (5)Reverse Input Voltage:5V; (6)Average Output Current:25mA; (7)Supply Voltage:0V to 20V; (8)Output Voltage:-0.5V to 20V; (9)Total Package Power Dissipation:294mW; (10)Lead Solder Temperature (Through Hole Parts Only):260℃ for 10 sec.

Features

HCPL-2232 features: (1)10 kV/μs Minimum Common Mode Rejection (CMR) at VCM = 1000 V; (2)Wide Operating VCC Range:4.5 to 20 Volts; (3)300 ns Propagation Delay Guaranteed over the Full Temperature Range; (4)5 Mbd Typical Signal Rate; (5)Low Input Current (1.6 mA to 1.8 mA); (6)Hysteresis; (7)Totem Pole Output (No Pullup Resistor Required); (8)Available in 8-Pin DIP, SOIC-8, Widebody Packages; (9)Guaranteed Performance from -40℃ to 85℃.

Diagrams
