Product Summary

The FCX717TA is a PNP silicon power transistor.

Parametrics

FCX717TA absolute maximum ratings: (1)Collector-base voltage, VCBO: -12V; (2)Collector-emitter voltage, VCEO: -12V; (3)Emitter-base voltage, VEBO: -5V; (4)Peak pulse current, ICM: -10A; (5)Continuous collector current, IC: -3A; (6)Base current, IB: -500mA; (7)Power dissipation at Tamb=25℃, Ptot: 1W; (8)Operating and storage temperature range, Tj, Tstg: -55 to +150℃.

Features

FCX717TA features: (1)2W power dissipation; (2)10A peak pulse current; (3)Excellent HFE characteristics up to 10 Amps; (4)Extremely low saturation voltage; (5)Extremely low equivalent on-resistance.

Diagrams

FCX717TA diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
FCX717TA
FCX717TA
Diodes Inc.
Transistors Bipolar (BJT) PNP Low Saturation
Data Sheet
0-1: $0.48
1-10: $0.38
10-100: $0.23
100-500: $0.18
500-1000: $0.14
