Product Summary

The STTH1R06A is a turbo 2 ultrafast high voltage rectifier. It is using ST turbo 2600V technology, is specially suited as boost diode in power factor corretion circuitry. The STTH1R06A is also intended for use as a free wheeling diode in power supplies and other power switching applications.

Parametrics

STTH1R06A absolute maximum ratings: (1)VRRM, repetitive peak reverse voltage: 600V; (2)IF(RMS), forward rms current, DO-41: 10A; SMA/SMB: 7A; (3)IF(AV), average forward current: 1A; (4)Tstg, storage temperature range: -65 to +175℃; (5)Tj, maximum operating junction temperature: 175℃.

Features

STTH1R06A features: (1)Ultrafast switching; (2)Low reverse recovery current; (3)Low thermal resistance; (4)Reduces switching and conduction losses.

Diagrams

STTH1R06A dimensions

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
STTH1R06A
STTH1R06A
STMicroelectronics
Rectifiers RECTIFIER
Data Sheet
0-1: $0.23
1-10: $0.20
10-100: $0.17
100-250: $0.14
