Product Summary
The STN851 is a low voltage fast-switching NPN power transistor. Its applications include emergency lighting, voltage regulators, relay drivers, high efficiency low voltage switching applications.
Parametrics
STN851 absolute maximum ratings: (1)VCBO, collector-base voltage: 150V; (2)VCEO, collector-emitter voltage: 60V; (3)VEBO, emitter-base voltage: 7V; (4)IC, collector current: 5A; (5)ICM, collector peak current: 10A; (6)IB, base current: 1A; (7)IBM, base peak current: 2A; (8)Ptot, total dissipation at Tamb=25℃: 1.6W; (9)Tstg, storage temperature: -65 to 150℃; (10)TJ, max. operating junction temperature: 150℃.
Features
STN851 features: (1)Very low collector to emitter saturation voltage; (2)High current gain characteristic; (3)Fast-switching speed.
Diagrams
Image | Part No | Mfg | Description | Pricing (USD) |
Quantity | |||||||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
STN851 |
STMicroelectronics |
Transistors Bipolar (BJT) NPN Lo-Volt Fast Sw |
Data Sheet |
|
|
|||||||||||||
STN851-A |
STMicroelectronics |
Transistors Bipolar (BJT) Low voltage NPN Power Transistor |
Data Sheet |
|
|
