Product Summary

The MAX2632EUK is a lowvoltage, low-noise amplifier for use from VHF to microwave frequency. Operating from a single +2.7V to +5.5V supply, the MAX2632EUK has a flat gain response to 900MHz. The low noise figure and low supply current of the MAX2632EUK makes its ideal for receive, buffer, and transmit IF applications. The MAX2632EUK is biased internally, eliminating the need for external bias resistors or inductors. The MAX2632EUK has a user-selectable supply current, which can be adjusted by adding a single external resistor. This allows customized output power and gain according to specific applications requirements. The MAX2632EUK features a shutdown pin that allows them to be powered down to less than 1μA supply current. Aside from a single bias resistor required for the MAX2632EUK, the only external components needed for this family of amplifiers are input and output blocking capacitors and a VCC bypass capacitor.

Parametrics

MAX2632EUK absolute maximum ratings: (1)VCC to GND -0.3V to 6V; (2)Input Power 5dBm; (3)OUT Current ±12mA; (4)IN to GND Voltage -1.2V to 1.2V; (5)Bias to GND Voltage 0.0V to 3V; (6)Voltage at SHDN Input -0.3V to (VCC + 0.3V); (7)Current into SHDN Input 100μA; (8)Operating Temperature Range -40℃ to +85℃; (9)Junction Temperature +150℃; (10)Storage Temperature Range -65℃ to +150℃; (11)Lead Temperature (soldering, 10s) +300℃.

Features

MAX2632EUK features: (1)Single +2.7V to +5.5V Operation; (2)Internally Biased (MAX2630/MAX2631); (3)Adjustable Bias (MAX2632/MAX2633); (4)6.6mA Supply Current (insensitive to supply; (5)voltage); (6)1μA Shutdown Current (MAX2631/MAX2633); (7)3.7dB Noise Figure; (8)13.4dB Gain; (9)Ultra-Small SOT Packages.
