Product Summary
The LM809M3-4.38 is a 3-pin microprocessor reset circuit. Its applications include microprocessor systems, computers, controllers, intelligent instruments, portable/battery-powered equipment and automotive.
Parametrics
LM809M3-4.38 absolute maximum ratings: (1)VCC: -0.3V to 6.0V; (2)Input current ,VCC pin: 20mA; (3)Output current ,reset pin: 20mA; (4)Rate of rise, VCC: 100V/μs; (5)ESD Rating: 2kV; (6)Ambient temperature range: -40 to +105℃; (7)Maximum junction temperature: 125℃; (8)Storage temperature range: -65 to +160℃; (9)Lead temperature: +300℃.
Features
LM809M3-4.38 features: (1)Precise monitoring of 3V, 3.3V, and 5V supply voltages; (2)Superior upgrade to MAX809/810; (3)Fully specified over temperature; (4)Guaranteed RESET output valid for VCC ≥1V; (5)Low supply current, 15μA typ.; (6)Power supply transient immunity.
