The LM2596S-5.0 regulator is a monolithic integrated circuit that provide all the active functions for a step-down (buck) switching regulator, capable of driving a 3A load with excellent line and load regulation. The LM2596S-5.0 is available in fixed output voltages of 3.3V, 5V, 12V, and an adjustable output version. Requiring a minimum number of external component, the regulator is simple to use and include internal frequency compensation? and a fixed-frequency oscillator. The LM2596S-5.0 operates at a switching frequency of 150 kHz thus allowing smaller sized filter components than what would be needed with lower frequency switching regulators. Available in a standard 5-lead TO-220 package with several different lead bend options, and a 5-lead TO-263 surface mount package.

Parametrics

LM2596S-5.0 absolute maximum ratings: (1)Maximum Supply Voltage 45V; (2)ON /OFF Pin Input Voltage -0.3 ≤ V ≤ +25V; (3)Feedback Pin Voltage -0.3 ≤ V ≤+25V; (4)Output Voltage to Ground; (5)(Steady State) -1V; (6)Power Dissipation Internally limited; (7)Storage Temperature Range -65℃ to +150℃; (8)Vapor Phase (60 sec.) +215℃; (9)Infrared (10 sec.) +245℃; (10)T Package (Soldering, 10 sec.) +260℃; (11)Maximum Junction Temperature +150℃.
