HCPL-M601

Surface Mountable, High Speed, Low Input Current Capability, 5mA, SO-5, Logic Gate Optocoupler

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.62~0.65 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.62~0.65

PartNumber:: HCPL-M601

Brand:: Agilent Technologies - Agilent | Pack: SO | D/C: 01+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. CoCo's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-07-20

From Other Seller

Part Number:HCPL-M601
US $0.62 - 0.65
ECA1HHG220

US $2.00 - 10.00 / Piece
(0) Remove
TMS320C6414TBGLZA7

US $58.00 - 65.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The HCPL-M601 is a small outline high CMR, high speed, logic gate optocoupler. The HCPL-M601 is suitable for high speed logic interfacing, input/output buffering, as line receivers in environments that conventional line receivers cannot tolerate, and are recommended for use in extremely high ground or induced noise environments. The applications of the HCPL-M601 are Isolated Line Receiver, Simplex/Multiplex Data Transmission, Computer-Peripheral Interface, Microprocessor System Interface, Digital Isolation for A/D, D/A Conversion, Switching Power Supply, Instrument Input/Output Isolation, Ground Loop Elimination, Pulse Transformer Replacement.

Parametrics

HCPL-M601 absolute maximum ratings: (1)Storage Temperature:-55℃ to +125℃; (2)Operating Temperature:-40℃ to +85℃; (3)Forward Input Current: IF:20mA; (4)Reverse Input Voltage: VR:5V; (5)Supply Voltage: VCC (1 Minute Maximum):7V; (6)Output Collector Current: IO:50mA; (7)Output Collector Power Dissipation:85mW; (8)Output Collector Voltage: VO:7V.

Features

HCPL-M601 features: (1)Surface Mountable; (2)Very Small, Low Profile JEDEC Registered Package Outline; (3)Compatible with Infrared Vapor Phase Reflow and Wave Soldering Processes; (4)Internal Shield for High Common Mode Rejection(CMR) HCPL-M601: 10,000V/μs at VCM=50V, HCPL-M611: 15,000V/μs at VCM=1000V; (5)High Speed: 10 Mbd; (6)LSTTL/TTL Compatible; (7)Low Input Current Capability: 5 mA; (8)Guaranteed ac and dc Performance over Temperature:-40℃ to 85℃; (9)Recognized under the Component Program of U.L.(File No. E55361)for Dielectric Withstand Proof Test Voltage of 2500 Vac, 1Minute.
