Product Summary

The M5L8155P-2 is a non-inverting 4-bit bidirectional bus driver. When the terminal CS is high-level, all outputs are in high-impedance state, and when low-level, the direction of the bidirectional bus can be controlled by the terminal DIEN. The applications of the M5L8155P-2 include bidirectional bus driver/receiver for various types of microcomputer systems.

Parametrics

M5L8155P-2 absolute maximum ratings: (1)supply voltage: 7 V; (2)input voltage, CS, DIEN, DI inputs: 5.5 V with respect to GND; (3)input voltage, DB input: VCC with respect to GND; (4)high-level output voltage: VCC with respect to GND; (5)power dissipation: 700 mW; (6)operating free-air temperature range: 0 to 75℃; (7)storage temperature range: -65 to +150℃.

Features

M5L8155P-2 features: (1)parallel 8-bit data bus buffer driver; (2)low input current DIEN, CS: IIL= -500μA max, DI, DB: IIL= -250μA max; (3)outputs can be connected with the CPU M5L8085AP: VOH=3.65 V min; (4)three-state output.

Diagrams

M5L8155P-2 block diagram
