Product Summary
The LT1117CST-3.3 is a positive low dropout regulator designed to provide up to 800mA of output current. The device is available in an adjustable version and fixed output voltages of 2.85V, 3.3V and 5V. The 2.85V version is designed specifically to be used in Active Terminators for the SCSI bus. All internal circuitry is designed to operate down to 1V input to output differential. Dropout voltage of the LT1117CST-3.3 is guaranteed at a maximum of 1.2V at 800mA, decreasing at lower load currents. On chip trimming adjusts the reference/output voltage to within ± 1%. Current limit of the LT1117CST-3.3 is also trimmed in order to minimize the stress on both the regulator and the power source circuitry under overload conditions. The low profile surface mount SOT-223 package allows the device to be used in applications where space is limited. The LT1117CST-3.3 requires a minimum of 10mF of output capacitance for stability. Output capacitors of this size or larger are normally included in most regulator designs.
Parametrics
LT1117CST-3.3 maximum ratings: (1)Input Voltage Operating Voltage: 15V; (2)Surge Voltage: 20V; (3)Operating JunctionTemperature Range: 0℃ to 125℃; (4)Storage Temperature Range: – 65℃ to 150℃.
Features
LT1117CST-3.3 features: (1)Space Saving SOT-223 Surface Mount Package; (2)Three-Terminal Adjustable or Fixed 2.85V, 3.3V, 5V; (3)Output Current of 800mA; (4)Operates Dowto 1V Dropout; (5)Guaranteed Dropout Voltage at Multiple Current Levels; (6)0.2% Line RegulatioMax; (7)0.4% Load RegulatioMax.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 LT1117CST-3.3 |
|
IC REG LDO 3.3V .8A SOT-223 |
Data Sheet |
|
|
||||||||||
|
LT1117CST-3.3#PBF |
|
IC REG LDO 3.3V .8A SOT-223 |
Data Sheet |
|
|
||||||||||
|
LT1117CST-3.3#TR |
|
IC REG LDO 3.3V .8A SOT-223 |
Data Sheet |
|
|
||||||||||
|
LT1117CST-3.3#TRPBF |
|
IC REG LDO 3.3V .8A SOT-223 |
Data Sheet |
|
|
||||||||||
