Product Summary
The LT1057ACN8 is a Dual and Quad, JFET Input Precision High Speed Op Amp. Its applications include precision, high speed instrumentation, fast, precision sample and hold, logarithmic amplifiers, D/A output amplifier, photodiode amplifier, voltage to frequency converters, frequency to voltage converters.
Parametrics
LT1057ACN8 absolute maximum ratings: (1)Supply voltage: ±20V; (2)Differential input voltage: ±40V; (3)Input voltage: ±20V; (4)Output short circuit duration: indefinite; (5)Operating temperature range: -55 to 120℃; (6)Storage temperature range: -65 to 150℃; (7)Lead temperature: 300℃.
Features
LT1057ACN8 features: (1)14V/μs slew rate: 10V/μs min.; (2)5MHz gain-bandwidth product; (3)Fast settling time: 1.3μs to 0.02%; (4)150μV offset voltage: 450μV max.; (5)Low voltage noise.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 LT1057ACN8 |
|
IC PREC OP-AMP JFET DUAL 8-DIP |
Data Sheet |
|
|
||||||||||
|
LT1057ACN8#PBF |
|
IC PREC OP-AMP JFET DUAL 8-DIP |
Data Sheet |
|
|
||||||||||
