Product Summary

The BAV99 is a small signal diode.

Parametrics

BAV99 absolute maximum ratings: (1)VRRM, maximum repetitive reverse voltage: 70V; (2)IF, average rectified forward current: 200mA; (3)IFSM, non-repetitive peak forward surge current, pulse width=1.0 second: 1.0A; pulse width=300microseconds: 8.0A; (4)Tstg, storage temperature range: -55 to +150℃; (5)Tj, operating junction temperature: -55 to +150℃.

Features

BAV99 characteristics: (1)VR, breakdown voltage: 70V; (2)VF, forward voltage: 715mV; (3)IR, reverse leakage: 2.5μA; (4)CT, total capacitance: 1.5pF; (5)trr, reverse recovery time: 6.0ns.

Diagrams

BAV99 connection diagram
