Product Summary
The Altima AC205KQM is a highly integrated 0.25u CMOS silicon solution. It combines all the functions of a 10/100 dual-speed bridged repeater, including PHY transceivers, an MII or 7-wire hard-wire configurable interface, two internal repeaters, and a two-port bridge with 32 KB embedded memory. The AC205KQM contains five 10BASE-T/100BASE-TX Fast Ethernet transceivers, one of which can be configured into a fullduplex uplink port. The transceiver of the AC205KQM performs all of the physical layer interface functions for 10BASE-T Ethernet on Category 3, 4, or 5 unshielded twisted pair (UTP) cable and 100BASE-TX Fast Ethernet on Category 5 UTP cable. The MII and 7-wire compatible MAC interface allows the AC205KQM to be designed into many different applications, reducing the number of separate devices necessary to meet multiple design requirements.
Parametrics
AC205KQM absolute maximum ratings: (1)Supply Voltage: 2.7 V ~ 5.5 V; (2)Operating Temperature: -40℃ ~ 85℃.
Features
AC205KQM features: (1)The highest level of silicon integration achieved for a five-port 10/100 bridged repeater; (2)MII or 7-wire port; (3)Fully compliant auto-negotiation; (4)Very small package 100-pin PQFP Cable detect mode typical < 20W; (5)Power down mode typical < 05W Provides easy product migration; (6)Provides seamless integration for WAN connections and system expansion; (7)Provides lowest overall cost and form factor for 10/100 repeater hub design and SOHO gateway and router design.
Diagrams
 |
