Product Summary

The SN74CB3T3306DCUR is a dual FET bus switch low voltage bus switch with 5V tolerant level shifter.

Parametrics

SN74CB3T3306DCUR absolute maximum ratings: (1)VCC, supply voltage range: 7V; (2)VIN, control input voltage range: 7V; (3)VI/O, switch I/O voltage range: 7V; (4)IIK, control input clamp current: -50mA; (5)II/OK, I/O port clamp current; (6)II/O, on-state switch current: ±128mA; (7)Tstg, storage temperature range: -65 to 150℃.

Features

SN74CB3T3306DCUR features: (1)Output voltage translation tracks VCC; (2)Supports mixed-mode signal operation on all data I/O ports; (3)5V tolerant I/Os with device powered up or powered down; (4)Bidirectional data flow with near-zero propagation delay; (5)Low on-state resistance; (6)Low input/output capacitance minimizes loading; (7)Low power consumption; (8)Ideal for low-power portable equipment.

Diagrams

SN74CB3T3306DCUR diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
SN74CB3T3306DCUR
SN74CB3T3306DCUR
Texas Instruments
Digital Bus Switch ICs Dual Bus Switch Voltage Translator
Data Sheet
0-1: $0.92
1-25: $0.71
25-100: $0.64
100-250: $0.58
