Product Summary

The NJT4030PT1G is a bipolar power transistor.

Parametrics

NJT4030PT1G absolute maximum ratings: (1)Collector-emitter voltage, VCEO: 40Vdc; (2)Collecor-base voltage, VCB: 40Vdc; (3)Emitter-base voltage, VEB: 6.0Vdc; (4)Base current-continuous, IB: 1.0Adc; (5)Collector current-continuous, IC: 3.0Adc; peak: 5.0Adc; (6)Total power dissipation, PD: 20W; (7)Operating and storage junction temperature, TJ, Tstg: -55 to +150℃.

Features

NJT4030PT1G features: (1)Collector-emitter sustaining voltage; (2)High DC current gain; (3)Low collector-emitter saturation voltage; (4)SOT-223 surface mount package; (5)Epoxy meets UL 94; (6)ESD rating: Human body model, 3B: >8000V; Machine model: >400V; (7)Pb-free.

Diagrams

NJT4030PT1G pin diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
NJT4030PT1G
NJT4030PT1G
ON Semiconductor
Transistors Bipolar (BJT) 40V 3A PNP BIPOLAR POWER TRANSISTOR
Data Sheet
0-1: $0.26
1-25: $0.20
25-100: $0.17
100-500: $0.12
500-1000: $0.09
Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
NJT4030PT1G
NJT4030PT1G
ON Semiconductor
Transistors Bipolar (BJT) 40V 3A PNP BIPOLAR POWER TRANSISTOR
Data Sheet
0-1: $0.26
1-25: $0.20
25-100: $0.17
100-500: $0.12
500-1000: $0.09
NJT4030PT3G
NJT4030PT3G
ON Semiconductor
Transistors Bipolar (BJT) 40V 3A PNP BIPOLAR POWER TRANSISTOR
Data Sheet
0-1: $0.23
1-25: $0.20
25-100: $0.17
100-250: $0.14
NJT4031NT1G
NJT4031NT1G
ON Semiconductor
Transistors Bipolar (BJT) NPN 40V LO SAT BP
Data Sheet
0-1: $0.28
1-25: $0.21
25-100: $0.17
100-500: $0.13
500-1000: $0.10
NJT4031NT3G
NJT4031NT3G
ON Semiconductor
Transistors Bipolar (BJT) NPN 40V LO SAT BP SOT223
Data Sheet
0-1: $0.28
1-25: $0.21
25-100: $0.17
100-250: $0.15
