LT1761ES5-2.5

SOT23-5, 100mA, Low Noise, LDO Micropower Regulator, SHDN Pin Voltage ±20V, 0.1mA

Rated 5 Rating 5 | reviews | Write a review

Price:: US $1.37~1.40 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $1.37~1.40

PartNumber:: LT1761ES5-2.5

Brand:: Linear Technology - Linear | Pack: SOT | D/C: 05+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. CoCo's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-07-20

From Other Seller

Part Number:LT1761ES5-2.5
US $1.37 - 1.40
ECA1HHG100

US $10.00 - 10.00 / Piece
(0) Remove
ECA1HHG220

US $2.00 - 10.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The LT1761ES5-2.5 is a micropower, low noise, low dropout regulator. With an external 0.01mF bypass capacitor, output noise drops to 20mVRMS over a 10Hz to 100kHz bandwidth. Designed for use in battery-powered systems, the low 20mA quiescent current makes them an ideal choice. In shutdown, quiescent current drops to less than 0.1mA. The LT1761ES5-2.5 is capable of operating over an input voltage from 1.8V to 20V, and can supply 100mA of output current with a dropout voltage of 300mV. Quiescent current is well controlled, not rising in dropout as it does with many other regulators. The LT1761ES5-2.5 regulator is a stable with output capacitor as low as 1mF. Small ceramic capacitor can be used without the series resistance required by other regulators.

Parametrics

LT1761ES5-2.5 absolute maximum ratings: (1)IN Pin Voltage ±20V; (2)OUT Pin Voltage ±20V; (3)Input to Output Differential Voltage ±20V; (4)ADJ Pin Voltage ±7V; (5)BYP Pin Voltage ±0.6V; (6)SHDN Pin Voltage ±20V; (7)Storage Temperature Range –65℃ to 150℃; (8)Lead Temperature (Soldering, 10 sec) 300℃.

Features

LT1761ES5-2.5 features: (1)Tiny 5-Lead SOT-23 Package; (2)Low Noise: 20mVRMS (10Hz to 100kHz); (3)Low Quiescent Current: 20mA; (4)Wide Input Voltage Range: 1.8V to 20V; (5)Output Current: 100mA; (6)Very Low ShutdowCurrent: < 0.1mA; (7)Low Dropout Voltage: 300mV at 100mA; (8)Fixed Output Voltages: 1.5V, 1.8V, 2V, 2.5V, 2.8V, 3V, 3.3V, 5V; (9)Adjustable Output from 1.22V to 20V; (10)Stable with 1mF Output Capacitor; (11)Stable with Aluminum, Tantalum or Ceramic Capacitors; (12)Reverse Battery Protected; (13)No Reverse Current; (14)No ProtectioDiodes Needed; (15)Overcurrent and Overtemperature Protected.
