Product Summary
The EMH4 is an NPN complex digital transistor. Its applications include inverter circuit, interface circuit and driver circuit.
Parametrics
EMH4 absolute maximum ratings: (1)Collector-base voltage, VCBO: 50V; (2)Collector-emitter voltage, VCEO: 50V; (3)Emitter-base voltage, VEBO: 5V; (4)Collector current, IC: 100mA; (5)Collector power dissipation, PD: 150mW; (6)Junction temperature, Tj: 150℃; (7)Range of storage temperature, Tstg: -55 to +150℃.
Features
EMH4 features: (1)Built-in biasing resistors; (2)Two DTC114T chips in one package; (3)Built-in bias resistors enable the configuration of an inverter circuit without connecting external input resistors; (4)The bias resistors consist of thin-film resistors with complete isolation to allow negative biasing of the input. They also have the advantage of completely eliminating parasitic effects; (5)Only the on/off conditions need to be set for operation, making the circuit design easy; (7)Lead free/RoHS compliant.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 EMH4 |
Other |
|
Data Sheet |
Negotiable |
|
||||||||||
 |
EMH4T2R |
ROHM Semiconductor |
Transistors Switching (Resistor Biased) DUAL NPN 50V 100MA |
Data Sheet |
|
|
||||||||||
